High-Precision Current Transducer
High-Precision Current Transducer
HANGZHI AIT-series are characterized by high accuracy of up to 10 ppm, low zero-drift, broad bandwidth and AC/DC universal and can capture current signals from inverter motors, power conditioners for PV, charging facilities for EVs.
Description
Application Area
| Product Model |
Rated Input(A) |
Overload Capacity(A) |
Conversion Ratio(Pri:Sec) |
Rated Output(mA/V) |
Working Power(V) |
Accuracy (ppm/%) |
Linearity (ppm/%) |
Bandwidth (kHz) |
Aperture (Φmm) |
Product Specifications |
|---|---|---|---|---|---|---|---|---|---|---|
| AIT60-SG | ±60 | ±72 | 600:1 | 100mA | ±15 | 10ppm | 2ppm | 500 | 26 |  |
| AIT200-SG | ±200 | ±240 | 1000:1 | 200mA | ±15 | 10ppm | 2ppm | 500 | 26 |  |
| AIT300-SG | ±300 | ±360 | 2000:1 | 150mA | ±15 | 10ppm | 2ppm | 500 | 26 | |
| AIT400-SG | ±400 | ±480 | 2000:1 | 200mA | ±15 | 10ppm | 2ppm | 500 | 26 | |
| AIT500-SG | ±500 | ±600 | 1500:1 | 333mA | ±15 | 10ppm | 2ppm | 500 | 38 | |
| AIT600-SG | ±600 | ±720 | 1500:1 | 400mA | ±15 | 10ppm | 2ppm | 500 | 38 | |
| AIT1000-SG | ±1000 | ±1200 | 1500:1 | 667mA | ±15 | 10ppm | 2ppm | 500 | 38 | |
| AIT1500-SG | ±1500 | ±1600 | 1000:1 | 1500mA | ±15 | 10ppm | 2ppm | 500 | 38 | |
| AIT2000-SG | ±2000 | ±2200 | 2000:1 | 1000mA | 220Vac | 50ppm | 20ppm | 300 | 50 | |
| AIT3000-SG | ±3000 | ±3300 | 3000:1 | 1000mA | 220Vac | 50ppm | 30ppm | 300 | 70 | |
| AIT4000-SG | ±4000 | ±4400 | 4000:1 | 1000mA | 220Vac | 50ppm | 30ppm | 300 | 70 | |
| AIT5000-SG | ±5000 | ±5500 | 5000:1 | 1000mA | 220Vac | 50ppm | 30ppm | 300 | 90 | |
| AIT6000-SG | ±6000 | ±6600 | 6000:1 | 1000mA | 220Vac | 50ppm | 30ppm | 300 | 90 | |
